Between one motorcycle CarPlay screen and the next, seven things differ, and for any one rider only two or three of them decide anything. Size is decided by your handlebar, not by preference. Brightness is decided by where you ride, and the automatic part matters as much as the peak number. The other five are yes-or-no questions with plain answers. Work out your two first, let the rest be tie-breakers, and ask every seller for the one number most listings leave out: the IP rating. Ours is IP67, and the weather section says what that does and does not cover.
| Difference | Decided by | On ours |
|---|---|---|
| Size | Your handlebar | 6.3-inch or 8-inch |
| Brightness | Where you ride | 700 nits (6.3) or 1,000 nits (8), auto brightness |
| Power | Whether you will wire it | Harness to the battery, switched with the key |
| Helmet audio | Whether you wear a headset | Two Bluetooth links: phone and headset |
| Cameras | Whether you want a record | Front and rear, 2560 x 1440, card not included |
| Tire pressure | How often you check | Two valve-cap sensors, pressure and temperature |
| Weather | Rain, or jet wash | IP67 housing (manufacturer-tested); rain yes, pressure jet no |
Size: your handlebar decides which motorcycle CarPlay screen fits
A screen lives in the space between your grips, above or in front of the clocks, and that space is fixed. On a naked bike, a sport bike or an adventure bike the bar is already busy with controls, and an 8-inch panel crowds them; the 6.3-inch is the one that fits. On a cruiser or a touring bike with wide bars and room above the tank, the 8-inch sits where it belongs and is easier to read at a glance. That is the whole logic behind our two sizes, and it is why we would talk you out of the 8-inch on a sport bike even though it is the brighter one.
Two smaller points that go with size. A bigger screen is a bigger sail at speed, and the ring bracket has to hold it; ours adjusts through 360 degrees, but the mount is doing more work with the larger panel. And in a drop, the screen is the first thing the bike lands on if it is mounted proud of the bars. Neither is a reason to avoid the 8-inch on a bike that suits it; both are reasons not to force it onto one that does not.
Brightness: the peak number and the automatic part
Nits are the number listings compete on, and they matter: the 8-inch model is rated at 1,000 nits and the 6.3-inch at 700, both IPS panels. In direct sun, more is better, and if you ride mostly in strong light with room for the larger screen, the 1,000-nit panel is the easier read. We are not going to give you a threshold for "sunlight readable," because we have not found a source we trust that states one, and the honest answer is that it depends on angle, on your visor, and on whether your sunglasses are polarized, which can darken some screens at some angles.
The automatic part is what you will notice day to day. A screen that drops its brightness when you ride into a tunnel and brings it back when you come out is one you stop thinking about; one stuck at full brightness is a lamp in your face at night. Both our sizes have automatic brightness. When you compare listings, look for that line as much as for the peak figure.
Power: wired to the battery, and what ACC means
Most screens in this class, ours included, wire to the bike with a harness. On ours the manufacturer's manual gives it in one line: connect the positive lead to the ACC circuit, the one that is live only when the key is on, and the negative lead to the negative terminal of the motorcycle's power supply. Wired that way the screen turns on and off with the bike instead of draining the battery in the garage. It is an hour's job for someone who has done it and an afternoon for someone who has not; if you have never wired anything to a bike, a friend who has is worth a beer. The manual also asks you to tie the harness away from the engine and the exhaust and to check that it does not pull tight at full steering lock; the full install, step by step from the manual, is here.
Some screens run from a USB port instead. That trades the wiring job for a cable on the bars and a screen that depends on whatever is powering the port. If you would rather not wire anything, that is the type to look for, and ours is not it.
Helmet audio: two Bluetooth links or one
Navigation prompts and calls are only useful on a motorcycle if they reach your helmet, and that depends on how many Bluetooth connections the screen can hold. Ours holds two: your phone on one, a Bluetooth helmet headset on the other, so the phone stays in your pocket and the audio goes where you can hear it. Pair the phone to the screen first, then the headset to the screen as the second device; the order is most of the battle, and the pairing guide walks through it, including what to do when the helmet stays silent.
A screen with a single Bluetooth link leaves audio to the phone, which means the phone has to talk to your headset directly and the screen is only a display. That works, and it is one more pairing to manage on a cold morning. If you ride without a headset, none of this matters; the map is on the screen either way and you simply will not hear the prompts.
Cameras: what 2K, 170 degrees, G-sensor and parking mode mean when something happens
Cameras on a motorcycle screen are for afterward. Ours are front and rear, each recording 2560 by 1440 through a 170-degree lens. The resolution is what lets a plate be read later, the wide lens is what catches the car that came from the side, and the G-sensor is what saves the clip: if the bike takes a hit, the sensor locks that recording so it is not overwritten. Parking monitoring records while the bike is parked, which is the case where you are least likely to be there and most likely to want the footage.
Two things to check on any camera listing. Whether a memory card is included; on ours it is not, footage saves to a microSD card you supply, and without one nothing is recorded, parked or moving, so buy the card before the first ride. And whether the cameras are front and rear or front only; a rear camera is the one that matters in the situation most riders worry about.
Tire pressure: what TPMS adds and what it does not replace
Ours comes with two valve-cap sensors, front and rear, that show live pressure and temperature on the screen and warn you when either goes out of range. What that buys you is the slow leak you would otherwise find at the next fuel stop, and the puncture that starts as a number falling while you ride. Fitting is a matter of screwing them on in place of the valve caps; they pair with the screen wirelessly, and the readings appear once you have ridden.
What it does not replace is the cold check. The pressure your owner's manual specifies is measured cold, before riding, with a gauge; the sensors read the tire as it is, which after ten minutes of riding is warmer and higher. Use the gauge to set pressure and the sensors to watch it. And since the sensors add a little mass at the valve, if a wheel develops a vibration after fitting them, have the balance checked.
Weather: "waterproof" is a housing, an IP rating is a test (ours is IP67)
Here is the number most listings leave out. "Waterproof housing" describes how the unit is built. An IP rating, the two-digit code like IP67, describes a test the unit passed: the first digit for dust, the second for water, from drips through jets to immersion. They are not the same statement, and a listing that gives you the word without the number is giving you the first and not the second.
Ours is IP67. When we first published this page the number was not in the specification we had, so we did not quote one; the manufacturer has since confirmed to us (September 2026) that IP67 is a tested rating, and it is now on the product page. In the code, the 6 means dust-tight and the 7 means the unit withstands temporary immersion in water, which puts riding in rain comfortably inside the rating. What IP67 does not cover is high-pressure jets, and the manual separately asks you to keep a pressure washer off the tire sensors when washing the bike. So: ride in the wet without worrying, and cover the screen and sensors or keep the jet off them at the car wash. Ask the same question of any other screen you are considering; if the seller has the number, they will tell you.
Which motorcycle CarPlay screen features matter, by bike
| You ride a | Decide first | Then |
|---|---|---|
| Naked or sport bike | Size (the 6.3-inch fits), brightness | Helmet audio |
| Adventure bike | Weather, cameras | Size, TPMS |
| Cruiser or tourer | Size (the 8-inch earns its space), helmet audio | Brightness |
| Daily commuter | Parking mode, TPMS | Power (will you wire it) |
Questions we get
Is a 6.3 or 8 inch motorcycle CarPlay screen better?
Neither in general. The 6.3-inch fits naked, sport and adventure bikes where the bar is busy; the 8-inch suits cruisers and touring bikes with room, and on ours it is the brighter of the two at 1,000 nits against 700.
How bright does a motorcycle CarPlay screen need to be?
Brighter is easier in direct sun, but angle, your visor and polarized sunglasses matter as much as the peak figure, and automatic brightness matters more day to day. We do not quote a threshold because we have not found a source we trust that states one.
Does a motorcycle CarPlay screen need to be wired to the battery?
Most in this class do, ours included: the manual has the positive lead go to the ACC circuit so the screen follows the key, and the negative to the bike's negative terminal. USB-powered screens exist and trade the wiring for a cable on the bars.
Is a motorcycle CarPlay screen with TPMS worth it?
If you do not check your tires often, yes: live pressure and temperature on the screen catch slow leaks and punctures while you ride. It does not replace setting cold pressure with a gauge before the ride.
Before you order
Pick the two criteria for your bike from the table, hold them against any screen you are looking at, and ask for the IP number. If the two point to a 6.3-inch or an 8-inch with cameras, TPMS and helmet audio, the Ride Screen is that, in both sizes. Still deciding whether you want a screen at all rather than a phone mount? That question is here. Not sure which size your bars take? Send us the bike model and we will say.
One-page answers to the questions this piece raises: does-cabinory-ride-screen-include-tire-pressure-sensors and is-cabinory-ride-screen-waterproof.
Sources
- Cabinory Ride Screen product page: sizes, brightness, cameras, sensors, Bluetooth links, harness, housing, per the manufacturer's specification (checked September 21, 2026).
- Manufacturer's English user guide for the X1 Pro series (installation and wiring, TPMS, wireless connection, precautions), on file; wiring wording quoted from it.
- Related Answers pages: which size, parking recording, helmet headset, tire sensors, waterproofing.
